Model |
CPCD25 |
| Load capacity |
mm |
2500 |
Weight distribtion with load(front/rear) |
kg |
5525/745 |
| Load center |
mm |
500 |
Weight distribtion without load (front/rear) |
kg |
1462/2185 |
| Tire type (front/rear) |
|
|
Battery voltage/capacity |
v/ah |
|
| Tilting angles (forward-backward) |
|
6°/12° |
Service brake |
|
Hydraulic-foot pedal |
| Free lift |
mm |
325 |
Parking brake |
|
Mechanical-hand lever |
| Max lifting speeds (without load/with load) |
mm/s |
530/500 |
Internal combution engine modle |
|
xinchang 490 BPG |
| Max driving speeds (without load/with load) |
km/h |
20/17.5 |
Internal combustion engine rate horsepower |
Kw/r.p.m |
37 |
| Max lowering speeds (without load/with load ) |
mm/s |
540/550 |
Internal combustion engine rate torque |
N.m/r.p.m |
148 |
| Max towing speeds (without load/with load ) |
N |
880/1140 |
Internal combustion engine number of clinder |
|
4 |
| Max gradeability (without load/with load ) |
% |
18 |
Internal combustion engine displacement |
L |
2.54 |
| Minintersecting aisle |
mm |
2710 |
Internal combustion engine fuel tank capacity |
L |
52 |
| Forks(L*W*H) |
mm |
920*122*40 |
Transmission number of speed fwd/rvs-rype |
|
1-1 Power shift T/M 2-2 Manual shift T/M |
| Minground clerance at lower point |
mm |
110 |
Total wegiht |
kg |
3647 |
